TERRATEC DMX 6Fire USB

Chi tiết sản phẩm

Manufacturer	TERRATEC
Model	DMX 6Fire USB
Chipset	Cirrus Logic (CS42426-CQZ 6 channel audio IC with PLL 114 dB / 192 KHz) Cypress (CY7068013A for the USB 2.0 port) Xilinx (Spartan XC2S100E programmable FPGA with 2700) cells
Special features	* dependent on the converter used 1 coaxial digital input/output (cinch) 1 headphone jack (6,3 mm) with separate volume controller 1 instrument input with gain control (6,3 mm jack) 1 microphone input with gain control (combo XLR / 6,3 mm jack) 1 MIDI interface In/Out (5-pin DIN) 1 optical digital input/output (TOS link) 1 phono input (RCA cinch) with a RIAA equalizer and gain control 20 dB pad switch 24 bit / 192 kHz A/D converter with 105 dB (A) SNR* (input 3/4) 24 bit / 192 kHz A/D converter with 114 dB (A) SNR* (input 1-6) 24 bit / 192 kHz A/D converter with 114 dB (A) SNR* (input 1/2) 4 analog inputs (cinch) 48V phantom power 6 analog outputs (cinch) Stereo to 5.1 surround-expander USB 2.0 audio system
Dimensions	200 x 160 x 45 mm (W x H x D) Weight: 800g
Package	1 x Adaptor (6,3 mm -> 3,5 mm mono) 1 x Adaptor (6,3 mm -> 3,5 mm stereo) 1 x CD driver & installer 1 x Device 1 x Power supply 1 x USB cable
